Dialysis RO Water System
AAMI/ISO-compliant ultra-pure water systems for haemodialysis — engineered to protect patient safety with consistently high-purity dialysis water meeting the strictest international standards.
Overview
Dialysis water quality is a matter of patient safety. During haemodialysis, a patient's blood is exposed to 120–150 litres of water per session — contaminants in the water can pass directly into the bloodstream, causing serious adverse reactions. Dialysis RO water systems are specially designed to produce ultra-pure water meeting AAMI TIR11, ISO 23500, and CPCB standards for haemodialysis water quality.
Aquatic Solutions designs and supplies complete dialysis water treatment systems for hospitals, dialysis centres, and nephrology units. Our systems incorporate multi-stage pre-treatment, double-pass RO, UV disinfection, and continuous recirculation loops to deliver consistently pure dialysis water. We also provide validation documentation, operator training, and comprehensive AMC to ensure ongoing compliance with NABH and AAMI standards.
Key Features
- Double-pass RO for ultra-pure water (conductivity < 1 µS/cm)
- AAMI TIR11 / ISO 23500 compliant water quality
- Continuous recirculation loop to prevent bacterial growth
- UV disinfection at point of use
- Online conductivity, TOC, and endotoxin monitoring
- Automated heat or chemical sanitisation
- Stainless steel 316L distribution loop
- NABH documentation and validation support
Get a Free Quote
We respond within 1 business day.
Technical Specifications
| Parameter | Specification |
|---|---|
| Water Quality Standard | AAMI TIR11 / ISO 23500 / NABH |
| RO Configuration | Double-pass RO |
| Product Water Conductivity | < 1 µS/cm |
| Endotoxin Level | < 0.25 EU/mL (AAMI standard) |
| Bacteria Count | < 0.1 CFU/mL (AAMI standard) |
| Capacity Range | 100 LPH – 5,000 LPH (per dialysis station requirement) |
| Distribution Loop | SS 316L with continuous recirculation |
| Sanitisation | Heat (80°C) or chemical (peracetic acid / citric acid) |
How It Works
Multi-Stage Pre-treatment
Feed water undergoes softening (to remove hardness), activated carbon filtration (to remove chlorine and chloramines), and 5-micron cartridge filtration before reaching the RO membranes.
First-Pass RO
Pre-treated water passes through the first-pass RO system, removing 97–99% of dissolved ions, bacteria, and endotoxins. Product water conductivity is typically 5–20 µS/cm after the first pass.
Second-Pass RO
First-pass permeate is further purified through a second RO pass, achieving conductivity below 1 µS/cm and endotoxin levels below AAMI standards.
UV Disinfection
Double-pass RO permeate passes through a high-dose UV system (> 40 mJ/cm²) to inactivate any residual bacteria and prevent biofilm formation in the distribution loop.
Recirculation Loop
Purified water is continuously recirculated through a SS 316L distribution loop at a velocity of > 1 m/s to prevent bacterial growth and ensure consistent water quality at every dialysis station.
Monitoring & Sanitisation
Online conductivity, TOC, and endotoxin sensors continuously monitor water quality. Automated heat or chemical sanitisation cycles are performed regularly to maintain microbiological control.
Capacity Options & Indicative Pricing
Prices are indicative and vary based on raw water quality, automation level, and site conditions. Contact us for an exact quotation.
| Capacity | Typical Application | Indicative Price (INR) |
|---|---|---|
| 100 – 500 LPH | 2–10 dialysis stations | ₹4 – 12 Lakhs |
| 500 – 2,000 LPH | 10–40 dialysis stations | ₹12 – 35 Lakhs |
| 2,000 – 5,000 LPH | 40–100 dialysis stations | ₹35 – 80 Lakhs |
* Prices are ex-works, exclusive of GST, civil work, and installation. Final price depends on site-specific requirements.
Industries & Applications
Why Choose Aquatic Solutions?
Service Coverage Across India
Aquatic Solutions supplies dialysis RO water systems to hospitals and dialysis centres across India — Mumbai, Pune, Hyderabad, Bangalore, Chennai, Delhi NCR, Ahmedabad, Kolkata, Nashik, and all major cities. We provide NABH documentation support and 24/7 AMC for critical healthcare applications.
